Disc and Ring Roller Components – precise components for conveyor belts

Product Description

Disc and ring roller components are key components used in the construction of rollers for conveyor belts. Their task is to stably guide the belt and ensure the durability and resistance of the entire transport system – even in demanding operating conditions.

At JOLA s.c., we specialize in the production of high-quality parts for disc and ring rollers. We offer, among others: steel and plastic rings, stamped and machined discs, spacer sleeves and separators, components manufactured according to the client's technical documentation. All elements are manufactured in our production hall in Poland, using modern machines and proven materials, which allows us to achieve high dimensional precision and wear resistance.

Key Features

  • High precision manufacturing
  • Resistance to wear and corrosion
  • Possibility of individual project realization
  • Production in Poland with certified materials
Technical drawing of the product
Technical drawing: Example configuration of disc/ring roller components
Stalowa tuleja dystansowa / Steel distance sleeve

Type L t Pipe
TL63/51 51 0,7 Ø 63,5
TL63/56 56 0,7 Ø 63,5
TL63/61 61 0,7 Ø 63,5
TL63/66 66 0,7 Ø 63,5
TL63/76 76 0,7 Ø 63,5
TL70/76 76 0,7 Ø 70,0
TL89/66 66 0,7 Ø 88,9
Stalowy pierścień zewnętrzny (spawany) / Steel outside ring (welded)

Type Pipe D1 D2 t1
PS51/65 Ø 51 65 65 2,0
PS51/72 Ø 51 72 72 2,0
PS63,5/78 Ø 63,5 78 78 2,0
PS76/90 Ø 76 90 90 2,0
PS70/90 Ø 70 90 90 2,0
PS88,9/110 Ø 88,9 110 110 2,0
PS108/137 Ø 108 137 137 2,0
